YJJ 1CO AB010-RO1A-CIT Electrochemistry Industrial Gas Sensor Supports Smaller Instruments

Product Description:

YJJ 1CO AB010-RO1A-CIT Electrochemistry Industrial Gas Sensor Supports Smaller Instruments

Features:

Product model: AB010-RO1A-CIT

Product Introduction: Series 1 analog gas sensor is a compact thin sensor using the most advanced urban technology. The life of the sensors has been extended by five years and the temperature and humidity range has been extended. Gas sensors are designed to operate in a variety of environments and harsh conditions. However, it is important to avoid exposure to high concentrations of solvent vapors during storage, installation to the instrument, and operation. When using sensors with printed circuit boards (PCBS), use degreaser before installing the sensors. Do not stick directly to or near the sensor, as solvents may cause the plastic to crack.

Performance characteristics:

Support for smaller instruments

Designed to meet the highest performance standards

Enhance performance in an extended environment

5 years expected service life

Meet RoHS standard

Parameters:

Measuring range: 0.5 ppm CO to 1000 ppm CO (EN 45544 application)

Overload: 2000 ppm CO

Onboard filter: Acid gas removal

Sensitivity: 50 nA/ppm ±10 nA/ppm

Weight: < 5 g

Operating temperature range: -40°C to +60°C

Operating humidity range: 5 %RH to 95 %RH No condensation

Working pressure range: 600 mbar to 1200 mbar
