FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps

FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps
FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps

Gambar besar :  FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps

Detail produk:
Tempat asal: Amerika Serikat
Nomor model: FMAMSDXX015WC2C3
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1
Harga: dapat dinegosiasikan
Kemasan rincian: Kotak Kertas
Waktu pengiriman: 3-5 hari kerja
Syarat-syarat pembayaran: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Menyediakan kemampuan: 5000 buah
Kontak

FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps

Deskripsi
Toleransi Non-linearitas: 2%FS Fungsi Pemindahan: 20~80%
Suhu pengoperasian: -40 ~+85°C Rentang Suhu Terkalibrasi: 5~50°C
Menyoroti:

piezoresistive force sensor for infusion pumps

,

microforce pressure sensor with warranty

,

ambulatory pump force sensor internal feeding



            FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps






Key Features:


Fully calibrated & temperature compensated via on‑board ASIC
Compensated for offset, sensitivity, temperature drift & nonlinearity
Built‑in short/open diagnostics
Overforce capability:3× full scale
Small form factor, stable sphere interface
Low power:Typ. 14 mW @ 3.3 V
Enhanced repeatability & reliability



 Applications:



Medical:Infusion pumps, enteral feeding, dialysis, surgical robotics
Industrial:Force/grip sensing, load detection, touch panels, thread tension monitoring
Others:Smart vending, precision weighing, high‑end appliances







Parameter

Min

Typ

Max

Unit

Test Condition
Full-Scale Force Range 0 - 15 N Compression only
Force Range (kgf) - 1.5 1.53 kg Equivalent force
Non-linearity Tolerance - - 2 %FS Calibrated range
Supply Voltage 3.0 3.3 3.6 V DC ±10% tolerance
Power Consumption - 14 - mW Operating state
Output Interface - I²C - - Digital, Address: 0x28
Transfer Function 20 - 80 % Core sensing range
Operating Temperature -40 - +85 °C Full range
Calibrated Temp Range 5 - 50 °C Factory compensation
Storage Temperature -40 - +85 °C Sealed packaging



FMAMSDXX015WC2C3 MicroForce Piezoresistive Force Sensor for Infusion/ambulatory Pumps Internal Feeding Pumps 0
