AFD5004R10 Vortex-shedding Liquid Flow Meter RS485 Output RC3/8 Thread

AFD5004R10 Vortex-shedding Liquid Flow Meter RS485 Output RC3/8 Thread
AFD5004R10 Vortex-shedding Liquid Flow Meter RS485 Output RC3/8 Thread AFD5004R10 Vortex-shedding Liquid Flow Meter RS485 Output RC3/8 Thread AFD5004R10 Vortex-shedding Liquid Flow Meter RS485 Output RC3/8 Thread AFD5004R10 Vortex-shedding Liquid Flow Meter RS485 Output RC3/8 Thread AFD5004R10 Vortex-shedding Liquid Flow Meter RS485 Output RC3/8 Thread

Gambar besar :  AFD5004R10 Vortex-shedding Liquid Flow Meter RS485 Output RC3/8 Thread

Detail produk:
Tempat asal: Cina
Nama merek: YJJ
Nomor model: AFD5004R10
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1
Harga: dapat dinegosiasikan
Kemasan rincian: PAKET STANDAR
Waktu pengiriman: 3-5 Workingdays
Syarat-syarat pembayaran: L/C, D/A, D/P, T/T, Western Union
Menyediakan kemampuan: 1000 buah/bulan
Kontak

AFD5004R10 Vortex-shedding Liquid Flow Meter RS485 Output RC3/8 Thread

Deskripsi
Tegangan suplai: 18–28 VDC Akurasi Pengukuran: Akurasi aliran < ±3,0% FS
Suhu sedang: 0–90°C Suhu Operasi Sekitar: -10°C hingga +65°C
Menyoroti:

Vortex-shedding liquid flow meter RS485 output

,

Medical air flow sensor RC3/8 thread

,

Liquid flow meter with warranty

AFD5004R10 Vortex-shedding Liquid Flow Meter RS485 Output RC3/8 Thread



Model Breakdown
AFD5004: Product series + flow range specification; flow range: 0.5–4 L/min (measurement of very low liquid flow rates)
R: Thread type = RC3/8 (British Standard Taper Pipe Thread—internal, DN10 pipe size)
10: Output signal is RS485 (Modbus-RTU); includes local digital display; no temperature sensing function



Specification:

Pressure rating Rated 10 bar; maximum short-term pressure resistance 16 bar
Wetted materials PPS engineering plastic and 304 stainless steel
Communication RS485 Modbus RTU
Supported baud rates 4800/9600/19200/115200 bps; configurable device address (1–32)
Housing Includes digital flow rate display; does not include temperature measurement
Wiring 4-core cable (Power +, Power -, 485A, 485B)



Comparison of available output models in the same series
AFD5004A10: Rc3/8 thread, 4–20 mA analog output, with display
AFD5004V10: Rc3/8 thread, 1–5 V voltage output, with display
AFD5004N10: Rc3/8 thread, NPN switch output
AFD5004P10: Rc3/8 thread, PNP switch output



AFD5004R10 Vortex-shedding Liquid Flow Meter RS485 Output RC3/8 Thread 0
